4. DESCRIPTION OF PARAMETERS
B–64160EN/01
116
3626
Number of pitch error compensation point at the farthest end in the negative
direction (for movement in the negative direction)
NOTE
When this parameter has been set, the power must be
turned off before operation is continued.
[Data type] Word axis
[Unit of data] Number
[Valid data range] 0 to 1023, 3000 to 4023
When using both–direction pitch error compensation, set the number of
pitch error compensation point at the farthest end in the negative direction
for a movement in the negative direction.
NOTE
1 For a movement in the positive direction, set the
compensation point number at the farthest end in the
negative direction in parameter No. 3621.
2 A set of compensation data items for a single axis should not
be set to lie astride 1023 and 3000.
3627
Pitch error compensation (absolute value) at reference position when a move-
ment to the reference position is made from the direction opposite to the direc-
tion of reference position return
NOTE
When this parameter has been set, the power must be
turned off before operation is continued.
[Data type] Word axis
[Unit of data] Detection unit
[Valid data range] –32768 to 32767
Set the absolute value of pitch error compensation at reference position
when a movement to the reference position is made from the negative
direction if the direction of reference position return (bit 5 (ZMI) of
parameter No. 1006) is positive or from the positive direction if the
direction of reference position return is negative.
