  2. Add red and embossed design characters "FANUC" on the cover of the display unit in i Series CNC and Power Mate i CNC

Add red and embossed design characters "FANUC" on the cover of the display unit in i Series CNC and Power Mate i CNC Additional Manual Page 2

Additional Manual
Edit. DATE Design
Description
DRAW. NO.
A-73123E-067
CUST.
01
01/08/28
First issue
Y.SONE
TITLE
Add red and embossed design characters
“FANUC” on the cover of the display unit
in i Series CNC and Power Mate i CNC
SHEET
1 / 3
1. Abstract
Add red and embossed design characters “FANUC” on the cover of the display unit in
FS16i/18i/21i/20i/160i/180i/210i/160is/180is/210is-MODEL A/B, FS15i/150i-MODEL A, Power Mate
i-D/H, PANEL
i, PANEL is, and Intelligent Terminal (ISA bus type).
The height of the embossed design characters is about 0.1mm.
This modification has been applied since October, 2001.
The position of the embossed design characters is referred to the figure below.
Red and embossed
design characters
“FANUC”
