Explanation Addition in FANUC Series 20i-MODEL B Connection Manual Hardware Supplement to Manual Page 3
Supplement to Manual
Edit.
DATE Design
Description
DRAW. NO.
B-64193EN/01-01
CUST.
TITLE
SHEET
2 / 2
D OPTICAL FIBER CABLE
The Series 20i - B uses the optical fiber cables for the following interfaces.
This table lists the usable combinations.
Interface Junction
Recommended
Optical fiber cable
Maximum
allowable
transmission
distance
Applicable
junction adapter
Remark
None
A66L-6001-0026#
L~
200m
Serial spindle
interface
*1
Exist
A66L-6001-0026#
L~
100m
*2
A63L-0020-0002
None
A66L-6001-0026#
L~
200m
I/O Link interface
*1
Exist
A66L-6001-0026#
L~
100m
*2
A63L-0020-0002
None
A66L-6001-0023#
L~
10m
Serial servo bus
(FSSB)
interface
None
A66L-6001-0026#
L~
100m
NOTE
1 When an optical fiber cable is used for connection.
2 Only one relay point is permitted. And you can relay two optical fiber cables on condition
that the sum of the line length of two cables is within the range of the maximum allowable
transmission distance or less.
Concluded.
