FS16i/18i Additional Manual Page 1

Additional Manual
FANUCSeries16i/18I
SPECIFICATIONS FOR POSITION
LOOP CONTROL FOR CONSTANT
VELOCITY
A - 63542- E
NO.
TITLE
NEWLY 1998.5.26 01
FANUC Series 16 i / 18i
SPECIFICATIONS FOR
POSITION LOOP CONTROL
FOR CONSTANT VELOCITY COMMAND
IN PMC AXIS CONTROL
Contents
1 General ------------------------------2
2 Parameters ------------------------3
This specifications may be modified for improvement without notice.
EDT. DATE DESIG. DESCRIPTION PAGE /003
