The warning message for expiration of the service lifetime Additional Manual Page 5

Additional Manual
EDT.
A
PPROVAL
DESIGN
PAGE
TITLE
No.
5
／
６
DATE
DESIGN
DESCRIPTION
DATE
The warning message for the expiration of
the service lifetime.
A
-63518
ＤＳ０１００－０４ ３
版
/
３．
３．３．
３．Signal
　◎
　◎　◎
　◎the output signal
　　
　　　　
　　 ＣＮＣ→ＰＭＣ　
　　
　
　
PMC
ADDRESS
#7 #6 #5 #4 #3 #2 #1 #0
F0093 LIFOVR
　
Name　　 LIFOVR periodic maintenance expiration signal
Details ［CLASSIFICATION］OUTPUT SIGNAL
　 ［FUNCTION］
The service lifetime expiration signal LIFOVR is set to ”1” when the lifetime of one
or more consumables registerd in the periodic maintenance screen has expired.
The signal becomes “0” by setting the data of the expired items in the periodic
maintenance screen again.
　　　　
Note 　　　This signal is enabled when the items are specified in periodic maintenance screen.
