Access to P-Code Variables through Custom Macro function Additional Manual Page 3

Additional Manual
3
Edit
A
pprvDesig.
Sheet
Title
Draw
No.
／
3
Date
Desig
Descri
p
tion
Date
FANUC Series16i /18i /21i-TA
A
ccess to P-Code Variables through
Custom Macro function.
A-76389E
2000.05.16
T.Saitoh
S.Isohata
2.2 Notice
(1) When power ON, the value of #8570=0, and value, 0 or 1, of this parameter is not
changed by RESET operation.
(2) The area of P-Code variables and expanded P-Code variables are decided by compile
parameter No.9037,9044 of Macro Executor.
(3) P-code variable number which can be read or written is up to “65536”.
(4) This function can be used with following software.
System software: Available on following edition or later,
FS16i-TA : B1FA-06 , B1F2-09 , B1F3-08
FS18i-TA : BEFA-06 , BEF2-09 , BEF3-08
FS21i-TA : DEF1-24 , DEF2-09
FS16i-MA : B0FA-06 , B0F2-10 , B0F3-08
FS18i-MA : BDFA-06 , BDF2-10 , BDF3-08
FS21i-MA : DDF1-24 , DDF2-10
Macro Executor: Available on following edition,
For FS16i-TA : BZG2-J9
For FS18i-TA : BZH2-J7
For FS21i-TA : DZ85-J7
For FS16i-MA : BZG1-J9
For FS18i-MA : BZG2-J4
For FS21i-MA : DZ80-J4
