  2. Series 30i-MODEL A, Improvement of stored stroke limit 1

Series 30i-MODEL A, Improvement of stored stroke limit 1 Additional Manual Page 11

Additional Manual
A-79360E
Title
Draw
No.
Ed. Date Design Description
Date Jan.06.’04 Design. Apprv.
9/9
page
FANUC Series 30i-MODEL A
Improvement of stored stroke limit 1
Caution
CAUTION
1. If the two points for specifying a forbidden area are identical, all areas
are handled as forbidden areas for stored stroke check
2. The size of a forbidden area must be set carefully. If
the size is set incorrectly, the stroke becomes infinite.
Note
NOTE
1. Specify diameter values for any axes for which diameter programming is
specified.
2. The area outside the area set by parameter No. 1326 and No. 1327 is a
prohibited area.
3. The EXLM signal is valid only when bit 2 (LMS) of parameter No. 1300
is set to 1.
4. The +EXLx signal is valid only when bit 0 (DLM) of Parameter No. 1301
is set to 1.
5. Parameter BFA (No. 1300 bit 7) selects whether the tool stops
immediately before the tool enters the prohibit area or immediately after
the tool has entered the prohibit area.
5. The over travel alarm check is executing in more detailed accuracy than
the displayed position. Therefore, there is a possibility to be generated
the over travel alarm when the position is displayed on the border
coordinate value.
Reference item
FANUC Series
30i/300i/300is-
MODEL A
USER’S MANUAL
(B-63944EN)
Stroke check
