FANUC Series 30i
TILTED WORKING PLANE COMMAND
The enhancement in tool axis direction command
A
- 79449
2002.02.20 T.Sasaki
11
/
12
S.Ide
19742 Lower limit of the movement range of the first rotation axis
[Input type] Parameter input
[Data type] Real path
[Unit of data] Degree
[Minimum unit of data]Depend on the increment system of the reference axis
[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting
(When the increment system is IS-B, -999999.999 to +999999.999)
In tool center point control for 5-axis machining (type 2) or tilted
working plane command, set the lower limit of the movement range of
the first rotation axis. When the movement range of the first rotation
axis is not specified, this parameter and parameter No. 19741 must both
be set to 0.
19743 Upper limit of the movement range of the second rotation axis
[Input type] Parameter input
[Data type] Real path
[Unit of data] Degree
[Minimum unit of data]Depend on the increment system of the reference axis
[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting
(When the increment system is IS-B, -999999.999 to +999999.999)
In tool center point control for 5-axis machining (type 2) or tilted
working plane command, set the upper limit of the movement range of
the second rotation axis. When the movement range of the second
rotation axis is not specified, this parameter and parameter No. 19744
must both be set to 0.
19744 Lower limit of the movement range of the second rotation axis
[Input type] Parameter input
[Data type] Real path
[Unit of data] Degree
[Minimum unit of data]Depend on the increment system of the reference axis
[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting
(When the increment system is IS-B, -999999.999 to +999999.999)
In tool center point control for 5-axis machining (type 2) or tilted
working plane command, set the lower limit of the movement range of
the second rotation axis. When the movement range of the second
rotation axis is not specified, this parameter and parameter No. 19743
must both be set to 0.
