FS 16i/18i-MA/MB, Improvement of acc./dec. time constant setting before interpolation (AI contour control, AI nano contour control, Advanced preview control) Supplement to Manual Page 3

Supplement to Manual
1.2 Parameter
1633
Parameter 2 for setting an acceleration for linear acceleration/deceleration before interpolation (time
used to reach the maximum machining speed during linear acceleration/deceleration before
interpolation) (For rotary axis)
[Data type] Word
[Data unit] 1 ms
[Data range] 0 to 4000
This parameter is used to set an acceleration for linear acceleration/deceleration
before interpolation. (For rotary axis)
In this parameter, set the time (time constant) used to reach the speed set in parameter
No.1630.
The acceleration, which is decided by this parameter, is available to the command
including the rotary axis. (The acceleration, which is decided by the parameter
No.1631, is available to the command excluding the rotary axis.)
Note
In case that the setting value is ‘0’, the acceleration, which is decided by the
parameter No.1631, is available to the command including the rotary axis.
1786
Parameter 2 (for AI contour control, AI nano contour control and Advanced preview control) for
setting an acceleration for linear acceleration/deceleration before interpolation (time used to reach the
maximum machining speed during linear acceleration/deceleration before interpolation) (For rotary
axis)
[Data type] Word
[Data unit] 1 ms
[Data range] 0 to 4000
This parameter is used to set an acceleration for linear acceleration/deceleration
before interpolation during AI contour control, AI nano contour control and
Advanced preview control mode. (For rotary axis)
In this parameter, set the time (time constant) used to reach the speed set in parameter
No.1770.
The acceleration, which is decided by this parameter, is available to the command
including the rotary axis. (The acceleration, which is decided by the parameter
No.1771, is available to the command excluding the rotary axis.)
Note
In case that the setting value is ‘0’, the acceleration, which is decided by the
parameter No.1771, is available to the command including the rotary axis.
Version
assent
end
Page
Name
No
Date
E
nd
Chan
g
es
date
FANUC Series 16i/18i-MA/MB，18i-MB5
Improvement of acc/dec time constant setting
before interpolation Specifications
2002.11.20
3/5
A-78443E
