3.5 Additional Manual Page 3

Additional Manual
(2) In case of FS15
i
-A/B
Specification of
Order List
Specification of
HDD unit
Remarks
A02B-0261-K011 A02B-0261-C174#C Maxtor (Fireball3 2F040J0) 40GB (NEW)
(Note 4) A02B-0261-C174#B Maxtor (D540X-4K) 20GB (OLD)
A02B-0261-C174#A Quantum (Fireball lct20) 10GB (OLD)
A02B-0261-C173 Quantum (Fireball lct10) 10.2GB (OLD)
(A02B-0261-C172) A02B-0261-C172 Quantum (Fireball EX3.2AT) 3.2GB (OLD)
(A02B-0261-C171) A02B-0261-C171 Quantum (Fireball EX2.5AT) 2.5GB (OLD)
Note 4) New HDD unit A02B-0261-C174#C is designed with upper compatibility as
against A02B-0261-C174#B, C174#A, C173, C172 and C171.
3. Notes
Please pay attention to followings when the new HDD unit is used.
(1) 2.1GB is available though the capacity of HDD itself is 40GB.
(2) HDD is the article of consumption. If you will be changed HDD unit that
have closed a life, you must exchange not the old same unit, the new
compatible one.
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
02
03.3.03
A
JIM
A
002
/
2
DESCRIPTIONDESIG. DATE
01 02.2.12
A
JIM
A
1st Edition
New unit added and Notes modified
3.5" Hard Disk Drive (HDD) unit
for Data Server
A
-82391E
