3. Specification of the Personal Computer
• FANUC requires the customer to buy and maintain the personal computer itself.
• FANUC is not responsible for the proper working about the personal computer itself
and any troubles caused by using the personal computer.
♦♦♦♦♦♦
(1) Specification of Personal Computer in Case that the Interface Board of
ISA Type are Used
ｷ This interface board for the personal computer is based on the ISA specifications and it
can be used into IBM-PC/AT or full compatible computer. (CPU of the computer must be
more than 486.)
ｷ The HSSB interface board uses 16 bytes of I/O space defined with rotary switch as mentioned
in "MAINTENANCE - Setting of Switched". The other ISA extension boards that use the same
resource with HSSB board can not be used.
ｷ Driver installation is required for using HSSB interface board. The driver for the HSSB
interface board is included in "Open CNC Driver Libraries Disk (order specification is A02B-
0207-K730).
ｷ Please examine the connection test including the communication between the personal
computer and CNC controller sufficiently.
ｷ Following shows the required power of the interface board for ISA type.
1ch version DC +5V, 1A
2ch version DC +5V, 1.5A
♦♦♦♦♦♦
(2) Specification of Personal Computer in Case that the Interface Board of
PCI Type are Used
ｷ This interface board for the personal computer is based on the PCI specifications and it
can be used into a computer with PCI slot(5V, ISA slot type).
ｷ Driver installation is required for using HSSB interface board. The driver for the HSSB
interface board is included in "Open CNC Driver Libraries Disk (order specification is A02B-
0207-K730). The revision of the driver must be Edition 1.6 or later for the board of PCI type.
ｷ Please examine the connection test including the communication between the personal
computer and CNC controller sufficiently.
ｷ Following shows the required power of the interface board for PCI type.
1ch version DC +5V, 0.8A
2ch version DC +5V, 1.0A
