0i Mate - MC Operators manual Page 847

Operators manual

Page of 872

/ 872

APPENDIX

B–64144EN/01

G. ALARM LIST

823

No. DescriptionFaulty location and remedy

SVPM

STATUS1

indica-

tion(*1)

Message

7n01 SPN_n_ : MOTOR

OVERHEAT

01 1 Check and correct the peripher-

al temperature and load status.

2 If the cooling fan stops, replace

it.

The internal temperature of the motor

exceeds the specified level.

The motor is used in excess of the

continuous rating, or the cooling com-

ponent is abnormal.

7n02 SPN_n_ : EX SPEED ER-

ROR

02 1 Check and correct the cutting

conditions to decrease the

load.

2 Correct parameter No. 4082.

The motor speed cannot follow a spe-

cified speed.

An excessive motor load torque is de-

tected.

The acceleration/deceleration time in

parameter No. 4082 is insufficient.

7n04 SPN_n_ : INPUT FUSE/

POWER

FAULT

04 Check the state of the input pow-

er supply to the SVPM.

Power supply phase was missed.

7n06 SPN_n_ : THERMAL

SENSOR DIS-

CONNECT

06 1 Check and correct the parame-

ter.

2 Replace the feedback cable.

The temperature sensor of the motor

is disconnected.

7n07 SPN_n_ : OVERSPEED 07 Check for a sequence error. (For

example, check whether spindle

synchronization was specified

when the spindle could not be

turned.)

The motor speed has exceeded

115% of its rated speed.

When the spindle axis was in position

control mode, positional deviations

were accumulated excessively (SFR

and SRV were turned off during

spindle synchronization control.)

7n09 SPN_n_ : OVERHEAT

MAIN CIRCUIT

09 1 Improve the heat sink cooling

status.

2 If the heat sink cooling fan

stops, replace the SVPM unit.

Abnormal temperature rise of the

power transistor radiator

7n11 SPN_n_ : OVERVOLT

POW CIRCUIT

11 Check the input power voltage and

change in power during motor de-

celeration. If the voltage exceeds

264 VAC, improve the power sup-

ply impedance.

Overvoltage of the DC link section

was detected.

7n12 SPN_n_ : OVERCUR-

RENT POW

CIRCUIT

12 1 Check the motor insulation sta-

tus.

2 Check the spindle parameters.

3 Replace the SVPM unit.

The amplifier output current is abnor-

mally high.

A motor–specific parameter does not

match the motor model.

Poor motor insulation

7n13 13 Replace the SVPM control printed

circuit board.

An abnormality was detected in the

SVPM control circuit.

(Internal RAM request)

7n18 SPN_n_ : SUMCHECK

ERROR PGM

DATA

18 Replace the SVPM control printed

circuit board.

Abnormality in an SVPM control cir-

cuit component is detected. (Pro-

gram ROM data is abnormal.)

7n19 SPN_n_ : EX OFFSET

CURRENT U

19 Replace the SVPM unit. Abnormality in an SVPM component

is detected. (The initial value for the U

phase current detection circuit is ab-

normal.)
