FS 16i/18i/21i-TA/TB, Additional Function of Spindle select by address P (Multi-spindle control) Specifications Supplement to Manual Page 2
Supplement to Manual
1. General
When the spindle is selected by address P in multi-spindle control (No.3703#3=1), S code
can be commanded without address P.
2. Specification
When the spindle is selected by address P in multi-spindle control (No.3703#3=1), S can
be commanded without address P if the parameter No.3706#2 is “1”. If address P is
omitted, last P in “S_P_” is used.
For the details of spindle select by address P in multi-spindle control, refer to
“FANUC Series 16i/18i/21i-TA/TB Spindle select by address P (Multi-spindle control)
Specifications (A-77777E)”
EDT
DATE
FANUC Series 16i/18i/21i-TA/TB
Additional function of spindle select by address P
(Multi-spindle control)
specifications
A-77777E-1
2/4
DS0100-04
DESIG.
DESCRIPTION
TITLE
NO.
PAGE
Contents Summary of FS 16i/18i/21i-TA/TB, Additional Function of Spindle select by address P (Multi-spindle control) Specifications Supplement to Manual
- Page 1FANUC Series 16i/18i/21i-TA/TB Additional function of spindle select by address P (Multi-spindle control) Specifications 1. General...................................................................................2 2. Specification ...................................................................
- Page 21. General When the spindle is selected by address P in multi-spindle control (No.3703#3=1), S code can be commanded without address P. 2. Specification When the spindle is selected by address P in multi-spindle control (No.3703#3=1), S can be commanded without address P if the parameter No.3706#2 i
- Page 33. Parameters #7 #6 #5 #4 #3 #2 #1 #0 3706 MPA [Data type] Bit MPA When the spindle is selected by address P in multi-spindle control (No.3703#3=1), if S code is commanded without address P, 0: P/S alarm 5305 occurs. 1: Last commanded address P of “S_P_” which is commanded in this path is used. If a
- Page 44. Signals Address P signals MSP00 to MSP15
[Classification] Output signal [Function] These signals report last commanded address P value in “S_P_” (Word data) [Output condition] These signals are set when “S_P_” is commanded in multi-spindle control (No. 3703#3=1). When “S_P_” has not b
