FANUC Series 16i/18i/21i-MB/TB
MULTI-SPINDLE CONTROL TYPE-C
A-79114E
03.04.04
M.Ito
3. PARAMETER
#0
#1
#2
#3
#4
#5
#6
#7
3713 MSC
[Data type] Bit
MSC Multi-spindle control TYPE-C is
0: unavailable.
1: available.
Note1) When the parameter MSC and the parameter MSI(multi-spindle control
TYPE-B, No.3709#2) are both “1”, multi-spindle TYPE-C becomes
available.
Note2) When this parameter is set, the power must be turned off before
operation is continued.
4. REFERENCE
FANUC Series 16i/18i/21i-MODEL B CONNECTION MANUAL (FUNCTION)
B-63523EN-1
9.10 MULTI-SPINDLE CONTROL
