Maintenance manual
3.START-UP PROCEDURE START-UP PROCEDURE FOR βi SVM B-65325EN/01
- 10 -
3.2 CONNECTING THE POWER
3.2.1 Checking the Voltage and Capacity of the Power
Before connecting the power, you should measure the AC power
voltage.
Table 3.2.1(a) Action for the AC power (200-V input type)
Permissible
voltage
fluctuation
width
Nominal
voltage
Action
-15%
+10%
3-phase
200 to
240VAC
SVM1-4i, SVM1-20i
SVM1-40i, SVM1-80i
Permitted.
Note) If the voltage is below the rated value,
the rated output may not be obtained.
-15%
+10%
1-phase
220 to
240VAC
SVM1-4i, SVM1-20i
Single-phase input is permitted when the power
supply is 380 to 415 VAC to neutral grounding.
Other than the above
SVM1-4i, SVM1-20i
SVM1-40i, SVM1-80i
Not permitted.
Use an insulating transformer to adjust the input
voltage.
Table 3.2.1 (b) list the input power specification. Use a power source
with sufficient capacity so that the system will not malfunction due to a
voltage drop even at a time of peak load.
Table 3.2.1 (b) AC power voltage specifications (200-V input type)
Model
SVM1-4i SVM1-20i SVM1-40i SVM1-80i
Nominal voltage rating 200 to 240VAC -15%, +10%
Power source frequency 50/60Hz ±1Hz
Power source capacity
(for the main circuit)
[kVA]
0.2 1.9 3.9 6.2
Power source capacity
(for the control circuit)
[kVA]
22
3.2.2 Connecting a Protective Ground
Check that the protective ground line is connected correctly.
3.2.3 Selecting the Ground Fault Interrupter That Matches the
Leakage Current
Check that a correct ground fault interrupter is selected.
