2.ALARM NUMBERS AND BRIEF DESCRIPTIONS TROUBLESHOOTING FOR βi SVM B-65325EN/01
- 36 -
2.2 FOR Series 16i, 18i, 20i, 21i, 0i, AND Power Mate i
2.2.1 Servo Alarm
Alarm No. Description Remark
361 Pulsecoder phase error (built-in) 3.2.7 (1)
364 Soft phase alarm (built-in) 3.2.7 (1)
365 LED error (built-in) 3.2.7 (1)
366 Pulse error (built-in) 3.2.7 (1)
367 Count error (built-in) 3.2.7 (1)
368 Serial data error (built-in) 3.2.7 (3)
369 Data transfer error (built-in) 3.2.7 (3)
380 LED error (separate) 3.2.7 (2)
381 Pulsecoder phase error (separate) 3.2.7 (2)
382 Count error (separate) 3.2.7 (2)
383 Pulse error (separate) 3.2.7 (2)
384 Soft phase alarm (separate) 3.2.7 (2)
385 Serial data error (separate) 3.2.7 (3)
386 Data transfer error (separate) 3.2.7 (3)
387 Sensor error (separate) 3.2.7 (2)
417 Invalid parameter 3.2.6
421 Excessive semi-full error 3.2.8
430 Servomotor overheat 3.2.5
432 Converter: control undervoltage 3.1.4
433 Converter: DC link undervoltage 3.1.1
436 Soft thermal (OVC) 3.2.3
438 Inverter: motor current alarm 3.1.9
439 Converter: DC link overvoltage 3.1.2
440 Converter: excessive deceleration power 3.1.3
441 Current offset error 3.2.8
444 Inverter: internal cooling fan stopped 3.1.5
445 Soft disconnection alarm 3.2.4
447 Hard disconnection alarm (separate) 3.2.4
448 Feedback mismatch alarm 3.2.8
449 Inverter: IPM alarm 3.1.7
453 Soft disconnection alarm (α Pulsecoder) 3.2.4
601 Inverter: cooling fan stopped of the radiator 3.1.6
603 Inverter: IPM alarm (OH) 3.1.8
