Available ATA Flash Cards and Compact Flash Cards with FS30i/300i/300is/31i/310i/310is/32i/320i/320is-MODEL A Additional Manual Page 2
Additional Manual
Edit.
DATE Design
Description
DRAW. NO.
A-65555E
CUST.
SHEET
1 / 2
The following table shows that the ATA Flash cards and Compact Flash cards, which are available to
the
FS30i/300i/300is/31i/310i/310is/32i/320i/320is-MODEL A, are confirmed by FANUC.
The marks on the table mean below.
Available : The card confirm to be worked by FANUC
－ : No planning to test
CF : Compact Flash
Available : Cancel the confirmation
FANUC does not guarantee that any other cards except for the list work well.
ATA Flash cards (CF cards) :
Usage
Manufacture Model Size
Data I/O automatic
operation by PCMCIA ports
Data Server
Remarks
SDCFB-128-801 128MB Available
Available
CF note1,3
SDCFB-256-801 256MB Available
Available
CF note1,3
SDCFB-384-801 384MB
－
Available
CF note1,3
SDCFB-512-801 512MB Available
Available
CF note1,3
SDCFB-512-J60 512MB Available
－
CF note1
SDCFB-1024-J60 1GB Available
－
CF note1
SanDisk
SDCFB-2048-J60 2GB Available
－
CF note1
HB28D032C8H 32MB Available
－
CF note1
HB28B064C8H 64MB Available
－
CF note1
HB28B128C8H 128MB Available
－
CF note1
HB28B256C8H 256MB Available
－
CF note1
HB28B512C8H 512MB Available
－
CF note1
HB28D096A8H 96MB
－
Available
HB28D160A8H 160MB
－
Available
HB28B192A8H 192MB Available Available
HB28B320A8H 320MB
－
Available
HB28B640A8H 640MB Available Available
Renesas Technology
HB28B1000A8H 1GB
－
Available
A02B-0236-K602 32MB Available
－
CF note1
A02B-0213-K201 192MB Available Available
FANUC note2
A02B-0213-K202 640MB Available Available
note1
Adaptor for Compact Flash cards
- For confirmation of data input/output operation and automatic operation based on the
PCMCIA port, the Compact Flash card adaptor (A02B-0303-K150) is used.
- For confirmation of data server operation, the adaptor (SDCF-31-03) manufactured by
SanDisk Corporation is used.
note2
These ATA Flash cards and Compact Flash cards available from FANUC.
TITLE
Available ATA Flash cards and Compact Flash
cards with
FS30i/300i/300is/31i/310i/310is/32i/320i/320is-
MODEL A
Rewrite overall
New issued
Kobayashi
Kobayashi
04.12.13
04.11.12
02
01
Nakamura
