Changing of the European Specification Main Breaker for FANUC LASER C2000-E & C4000-E Additional Manual Page 3
Additional Manual
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
003/3
DESCRIPTIONDESIG.DATE
01 05.07.06
Koba
y
ashi
N
ewl
y
Changing of the European specification
main breaker for FANUC LASER
C2000-E & C4000-E
A-81053E-110
Because the short-circuit interception capacity of the main breaker changes, the sticker is
changed as shown in the figure below.
4. Application
MODEL Application
C2000-E
Applied from the manufacturing in August,2005
C4000-E
Applied from the manufacturing in September,2005
Breaker Handle
Sticker
【Before】
【After】
Contents Summary of Changing of the European Specification Main Breaker for FANUC LASER C2000-E & C4000-E Additional Manual
- Page 1Changing of the European specification main breaker for FANUC LASER C2000-E & C4000-E 1. Outline In the European specification (EUR) of FANUC LASER C2000-E & C4000-E, it changes the terminal shape specification of the main breaker as well as a domestic specification The terminal for the cable connec
- Page 23-2. Changing of terminal for cable connection（All models of EUR specification are the Screw Terminal specification as well as a domestic specification. ） Please connect cable to use the recommended solderless terminal for each breaker, because it changes the specification from a past Box Terminal t
- Page 3Because the short-circuit interception capacity of the main breaker changes, the sticker is changed as shown in the figure below. Breaker Handle Sticker 【Before】 【After】 4. Application MODEL Application C2000-E Applied from the manufacturing in August,2005 C4000-E Applied from the manufacturing in S
