FS16i/18i/21i-MA, FS16i/18i-TA Extended superimposed control of PMC axis Additional Manual Page 3

Additional Manual
Ed.
Page
Name
No.
Date Contents
Draw up
FS16
i
/18
i
/21
i
-MA, FS16
i
/18
i
-TA
Extended superimposed control of PMC
axis
A-78498
2001.05.18
3/5
1.1
Outline
The CNC program waits until the end of the PMC superimposed axis moving in the
current superimposed control of a PMC axis.
CNC PMC
Moving X-axis by superimposed command
O0001;
start O0001
N100 G97 M12;
N110 G00 Z100.;
N120 G01 Z150. F150.;
N130 X150.;
N140;
;
stop X-axis
;
M30;
%
The above CNC program (O0001) starts during X-axis moving by superimposed
control of PMC axis. The program runs until N120 and stop. The N130 block starts
after waiting until end of PMC axis moving.
The some of these limitations are removed by this extension function as a result the
CNC program runs as continuously as possible.
