  2. FANUC Series 16i-MB

FANUC Series 16i-MB Additional Manual Page 12

Additional Manual
19680 Mechanical unit type
[Data type] Byte
[Valid data range] 0 to 21
Specify the type of the mechanical unit.
PRM19680
Mechanical unit
type
Controlled rotation
axis
Master and slave
0
Mechanism having no
rotation axis
2
Tool rotation
type
Two rotation axes of
the tool
The first rotation axis is the master,
and the second rotation axis is the
slave.
12
Table rotation
type
Two rotation axes of
the table
The first rotation axis is the master,
and the second rotation axis is the
slave.
21 Mixed type
One rotation axis of the
tool ＋ one rotation
axis of the table
The first rotation axis is the tool
rotation axis, and the second
rotation axis is the table rotation
axis.
First rotar
y
axis
(
master
)
Second rotar
y
axis
(
slave
)
First rotar
y
axis
(
master
)
Second rotary axis (slave)
Tool rotary
axes
Table rotary
axes
NOTE
A hypothetical axis is also counted as a controlled rotary axis.
<Hypothetical axis>
In some cases, it is convenient to use an imaginary rotary axis whose
angle is fixed to a certain value. For example, suppose that a tool is
mounted in a tilted manner through an attachment. In such a case,
the rotary axis considered hypothetically is a hypothetical axis. Bits 0
and 1 of parameter No. 19696 determine whether each rotary axis is
an ordinary roatry axis or a hypothetical axis.
A-79097E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Description
Date
FANUC Series 16i–MB, 18i–MB5
Thermal growth compensation
along tool vector Specifications
Jul.11.2003
T.Horie H.Kouzai
11/17
Previous page
Next page
