OPERATION

B–64154EN/01

4. AUTOMATIC OPERATION

401

The following procedure is given as an example. For actual operation,

refer to the manual supplied by the machine tool builder.

1 Press the single block switch to stop automatic operation. When the

mirror image function is used from the begining of operation, this step

is omitted.

2 Press the mirror image switch for the target axis on the machine

operator’s panel.

Alternatively, turn on the mirror image setting by following the steps

below:

2–1 Set the MDI mode.

2–2 Press the

OFFSET

SETTING

function key.

2–3 Press the

[SETING] soft key for chapter selection to display

the setting screen.

SETTING (MIRROR IMAGE) O0020 N00001

MEM

* * * *

* * * * * *

14 : 47 : 57

MIRROR IMAGE X = (0 : OFF 1 : ON)

MIRROR IMAGE Y = 0 (0 : OFF 1 : ON)

MIRROR IMAGE C = 0 (0 : OFF 1 : OM)

OFFSET

WORK (OPRT)

SETING

2–4 Move the cursor to the mirror image setting position, then set

the target axis to 1.

3 Enter an automatic operation mode (memory mode or MDI mode),

then press the cycle start button to start automatic operation.

⋅ The mirror image function can also be turned on and off by setting bit

0 of parameter 0012 to 1 (on) or 0 (off).

⋅ For the mirror image switches, refer to the manual supplied by the

machine tool builder.

Operations, such as manual operaton, automatic reference position return,

movement in repositioning, and movement related to tool position

compensation and C–axis position compensation cannot be reversed.

Procedure

Explanations

Limitations
