FANUC Series 16i/18i/21i Additional Manual Page 10
Additional Manual
2002/08/29
Parameter
#7 #6 #5 #4 #3 #2 #1 #0
13102 TAD
[Data type] Bit
TAD The current position is not displayed axis of the current position part
is
0: Null display
1: Top alignment display
NOTE
1. When this parameter has been set, the power must
be turned off before operation is continued.
2. The contents that parameter NDPx(bit 0 of
parameter No.3115) modified come into effect after
the power supply is mutilated.
3. This function becomes invalidity in 7-soft key type
display of the T series 2-path control systems.
Please use a parameter No. 3130, in the case that
you want to do the top alignment display with the
same system.
#7 #6 #5 #4 #3 #2 #1 #0
3115 NDAx NDPx
[Data type] Bit
NDPx Display of the current position for each axis
0: The current position is displayed.
1: The current position is not displayed.
NDAx Position display using absolute coordinates and relative coordinates is:
0: Performed.
1: Not performed. (Machine coordinates are displayed.)
Axis display order for current position display screens
3130
[Data type] Byte axis
[Valid data range] 0, 1 to the number of controlled axes
This parameter specifies the order in which axes are displayed on the
current position display screens (absolute, relative, overall, and
handle interrupt screens) during two-path control when the 7-pieces
type soft key display is used.
Edit
10/12
Date Si
g
nature
Descri
p
tion
A
-79605E
Drawing No.
Page
FANUC Series 16i/18i/21i-B
Title
