FANUC Series 16i/18i/21i Additional Manual Page 2

Additional Manual
2002/08/29
1 Top alignment display of position display
General
This function aligns the next axis to the display location of the
undisplay axis the top in the case of the current position is not
isplayed(parameter NDPx(bit 0 of parameter No.3115) is set to 1). d
Explanation
In the case that the ordinariness parameter NDPx(bit 0 of parameter
No.3115) is set to 1 the current position display of the undisplay axis
becomes null. By parameter TAD(bit 0 of parameter No. 13102) is set
to 1 undisplay axis is not been null and aligns the next axis to the
isplay location of the top. d
Limitation
This function becomes invalidity in 7-soft key type display of the T
series 2-path control systems.
Please use a parameter No.3130, in the case that you want to do the
op alignment display with the same system. t
Edit
2/12
Date Si
g
nature
Descri
p
tion
A
-79605E
Drawing No.
Page
FANUC Series 16i/18i/21i-B
Title
Previous page
Next page

Contents Summary of FANUC Series 16i/18i/21i Additional Manual

  • Page 1FANUC Series 16i /18i /21i –MB/TB Improvement of the position display (Display location top alignment) Specifications Contents 1 TOP ALIGNMENT DISPLAY OF POSITION DISPLAY .............................................................................. 2 Title FANUC Series 16i/18i/21i-B Drawing No. A-7
  • Page 21 Top alignment display of position display General This function aligns the next axis to the display location of the undisplay axis the top in the case of the current position is not displayed(parameter NDPx(bit 0 of parameter No.3115) is set to 1). Explanation In the case that the ordinariness par
  • Page 3Example The 2nd axis and the 4th axis undisplay(parameter NDPx(bit 0 of parameter No.3115) is set to 1) as case of it is the example of a usually display and top alignment display. 12-soft key type display (1) Absolutely coordinate [Usually display(No.13102#0="0")] [Top alignment display(No.13102#0=
  • Page 4(2) All [Usually display(No.13102#0="0")] [Top alignment display(No.13102#0="1")] Title FANUC Series 16i/18i/21i-B Drawing No. A-79605E Page Edit Date Signature Description 4/12 2002/08/29
  • Page 5(3) current position display [Usually display(No.13102#0="0")] [Top alignment display(No.13102#0="1")] Title FANUC Series 16i/18i/21i-B Drawing No. A-79605E Page Edit Date Signature Description 5/12 2002/08/29
  • Page 6(4) Program check [Usually display(No.13102#0="0")] [Top alignment display(No.13102#0="1")] Title FANUC Series 16i/18i/21i-B Drawing No. A-79605E Page Edit Date Signature Description 6/12 2002/08/29
  • Page 77-soft key type display (1) Absolutely coordinate [Usually display(No.13102#0="0")] [Top alignment display(No.13102#0="1")] Title FANUC Series 16i/18i/21i-B Drawing No. A-79605E Page Edit Date Signature Description 7/12 2002/08/29
  • Page 8(2) All [Usually display(No.13102#0="0")] [Top alignment display(No.13102#0="1")] Title FANUC Series 16i/18i/21i-B Drawing No. A-79605E Page Edit Date Signature Description 8/12 2002/08/29
  • Page 9(3) Offset [Usually display(No.13102#0="0")] [Top alignment display(No.13102#0="1")] Title FANUC Series 16i/18i/21i-B Drawing No. A-79605E Page Edit Date Signature Description 9/12 2002/08/29
  • Page 10Parameter #7 #6 #5 #4 #3 #2 #1 #0 13102 TAD [Data type] Bit TAD The current position is not displayed axis of the current position part is 0: Null display 1: Top alignment display NOTE 1. When this parameter has been set, the power must be turned off before operation is continued. 2. The contents th
