FANUC Series 16i /18i /21i Additional Manual Page 3
Additional Manual
Edit
Apprv.Desig.
Sheet
Title
Draw
No.
3
/
3
Date
Design
Descri
p
tion
Date
FANUC Series16i/18i/21i–MB, 18i–MB5
Improvement of AI contour control
/ AI nano contour control
040322
A-79490E
When parameter AIH (No.7057#1) is set to “1”with inch input and millimeter output during AI contour
control / AI nano contour control mode, CNC does the following inch/metric conversion before executing the
acceleration/deceleration before interpolation. By this method, CNC controls the acceleration/deceleration so
that the time constant of acceleration /deceleration becomes the same as that of millimeter input.
( inch input : inch, deg unit )
G01 Xa Bb Fc ;
X : Linear axis , B: Rotation axis
Convert to millimeter input command so that the each axis movement and feedrate in inch
input becomes the same as those of millimeter input.
( millimeter input : mm, deg unit )
G01 X[ a × 25.4 ] Bb F[ c × √ ((a × 25.4)
2
+ b
2
) / √ (a
2
+ b
2
) ] ;
X : Linear axis , B: Rotation axis
2. Parameter
#7 #6 #5 #4 #3 #2 #1 #0
7057 AIH
[Data type] Bit
AIH At inch input and millimeter output, the feedrate control of AI contour control / AI nano
contour control mode :
0 : Feedrate is calculated with 1 inch = 1 deg.
1 : Feedrate is calculated with 1 mm = 1 deg.
(The time constant of rotation axis becomes the same as that of linear axis.)
