FANUC Series 16i/18i-MA/TA Bidrectional pitch error compensation function Additional Manual Page 7

Additional Manual
Edit
6/11
FANUC Series 16i/18i-MA
FANUC Series 16i/18i-TA
Bidirectional pitch error compensation
A-77810E
Drawing No.
Title
Page
02 99/07/19 N.Aizawa Modified
p
a
g
e10-14
03 00/04/28
Added T series, Modified page10
Date Design
Descri
p
tion
Date
1999/06/23
Design
N.Aizawa
Approv
E.Genma
When the travel direction changes from negative to positive at the position of -40.0, the
compensation for the reverse of the travel direction is output.
5. Parameter
#7 #6 #5 #4 #3 #2 #1 #0
3605 BDP
Data type : Bit axis
BDP : Specifies whether to use bidirectional pitch error compensation.
0 : Do not use.
1 : Use.
NOTE
When this parameter is set, the power must be turned off before
operation is continued.
3620 Number of the pitch error compensation position for the reference position for
each axis
Data type : Word axis
Unit of data : Number
Valid range : 0 to 1023, 3000 to 4023
Set the number of the pitch error compensation position for the reference
position for each axis
NOTE
When this parameter is set, the power must be turned off before
operation is continued.
A pulse of -2 is the result of the following calculation:
-2 = - ( ( -1 ) - ( -3 ) )
Pitch error associated with the
negative-direction absolute value at the
position of -40.0
Pitch error associated with the positive-direction
absolute value at the position of -40.0
