Symbol & English type key MDI for Series 0i/0i-Mate MODEL B Additional Manual Page 3

Additional Manual
１．Overview
This report describes information of symbol & English key type MDI unit for
Series 0i/0i-Mate Model B.
２．Specification No.
9"monochrome CRT/MDI unit A02B-0299-C041#MB(M Series)
A02B-0299-C041#TB(T Series)
7.2"monochromeLCD/MDI unit A02B-0299-C071#MB(Graphic display, M Series)
A02B-0299-C071#TB(Graphic display, T Series)
A02B-0299-C076#MB(Character display, M Series)
A02B-0299-C076#TB(Character display, T Series)
8.4"color LCD/MDI unit A02B-0299-C081#MB(M Series)
A02B-0299-C081#TB(T Series)
Separate small MDI unit A02B-0279-C120#MB(M Series)
A02B-0299-C120#TB(T Series)
Separate full key MDI unit A02B-0210-C122#MB(For 7.2",8.4"LCD unit only,M Series)
A02B-0210-C122#TB(For 7.2",8.4"LCD unit only,T Series)
A02B-0279-C122#MB(For 10.4"LCD only vertical type,
M Series)
A02B-0279-C122#TB(For 10.4"LCD only vertical type,
T Series)
A02B-0279-C121#MB(For 10.4"LCD only horizontal type,
M Series)
A02B-0279-C121#TB(For 10.4"LCD only horizontal type,
T Series)
(*) Please positively order these specifications, instead of the current specifications
of symbol type MDI.
3.Others
Concerning connection, outline and weight, these units are the same as
the current units.
EDIT.
SHEET
DRAW. NO.
CUST.
TITLE
002/4
DESCRIPTIONDESIG.DATE
A-80946E
FANUC LTD
