2.4 Protocol

Only direct command on SNP-X protocol is available in FS16.

ETP also must use the same protocol and the same command only.

The process required for writing data more than 3 bytes is the same as

that lass than 2bytes.

Please refer the documents of SNP-X protocol for the detail of SNP-X protocol.

2.5 Caution

1) This function can not be used with the function that uses DMA for data

sending of RS-232C used in C language executor function, which is activated

by setting bit 3 of parameter No.8659.

2) In i series it is possible to use from the following hardware and software.

NAME

DRAWING NUMBER

EDITION

CPU CARD A20B-3300-0050 from 10E

SERIES EDITION SERIES EDITION

B0F1 from 15 ???? from ??

B1F1 from 14 ???? from ??

BDF1 from 15 ???? from ??

BEF1 from 14 ???? from ??

3) In i series, this function can not be used with the Touch Panel function on LCD.

4) ETP is Touch Panel made by DIGITAL Co. Ltd.. ETPs which can be connected

with FS16 are as follows.

* GP-450E

* GP-550T

* GP-550S

Edit

A-60292EN

FS16/18-MC/TC , FS16i/18i/21i-MA/TA

External touch panel interface

Title

Drawin

No.

Data Si

nature

First edition

98/07/17 Takeuchi

1998/07/10

Descri

tion

02 99/12/15 Takeuchi Addition of FS21i
