PROGRAMMING9. SPINDLE SPEED FUNCTION

B–63604EN/01

102

NOTE

1 When an alarm is issued in automatic operation, a single

block stop occurs. The spindle overheat alarm is indicated

on the CRT screen, and the alarm signal “SPAL” is output

(set to 1 for the presence of an alarm). This signal is cleared

by resetting.

2 Even when reset operation is performed after an alarm

occurs, the alarm is issued again unless the cause of the

alarm is corrected.

3 No check is made during spindle stop state (*SSTP = 0).

4 By setting the parameter (No. 4913), an allowable range of

speed fluctuations can be set which suppresses the

occurrence of an alarm. However, an alarm is issued one

second later if the actual speed is found to be 0 min

–1

5 The values of p, q, and r specified in the G26 block are set

in the following parameters. If the specification of p, q, or r

is omitted, the value set in the corresponding parameter is

referenced.

p : Parameter No. 4914

q : Parameter No. 4911

r : Parameter No. 4912

6 Bit 0 (FLR) of parameter No. 4900 can be used to specify

0.1% as the units of the specified q and r values.
