Series 21i/210i - TB Operators manual Page 793

Operators manual

Page of 808

/ 808

2/2

PAGE

EDT.

DATE

DESIGN

DESCRIPTION

TITLE

No.

/210

s - TA

/210

- TB OPERATOR’S MANUAL

Explanation addition of “Rigid tapping”

B-63084EN/02-3, B-63604EN/01-1

01 01.10.25 Newl

istered

13.7.1 Front Face Rigid Tapping Cycle (G84) /

Side Face Rigid Tapping Cycle (G88)

The description is added to “S command”.

Limitations

S command

•

The S command, which is specified at rigid tapping, is cleared at commanding Rigid

Tapping Cancel and the condition is the same that S0 is commanded.

13.7.2 Rigid Tapping Cancel (G80)

The chapter “13.7.2” is added.

The rigid tapping cycle is canceled.

For how to cancel this cycle, please see II-13.3.4.

Note

When Rigid Tapping Cancel is commanded, the S command, which is used at rigid

tapping, is also cleared. (It is the same that S0 is commanded.)

Therefore, the S command, which is specified for rigid tapping, can not be used at

blocks after Rigid Tapping Cancel. Please re-specify S command after Rigid Tapping

Cancel if necessary.
