APPENDIX

B–63604EN/01

G. ALARM LIST

733

Number ContentsMessage

5036 ADDRESS R NOT DEFINED IN

G81–G86

Point R was not specified for the canned cycle for the B–axis.

5037 ADDRESS Q NOT DEFINED IN G83 Depth of cut Q was not specified for the G83 code (peck drilling cycle).

Alternatively, 0 was specified in Q for teh B–axis.

5038 TOO MANY START M–CODE

COMMAND

More than six M codes for starting movement about the B–axis were

specified.

5039 START UNREGISTERED B–AXIS

PROG

An attempt was made to execute a program for the B–axis which had

not been registered.

5040 CAN NOT COMMANDED B–AXIS

MOVE

The machine could not move about the B–axis because parameter

No.8250 was incorrectly specified, or because the PMC axis system

could not be used.

5041 CAN NOT COMMANDED G110

BLOCK

Blocks containing the G110 codes were successively specified in tool–

tip radius compensation for the B–axis.

5046 ILLEGAL PARAMETER (ST.COMP) Parameters related to straightness compensation have been erro-

neously specified. Possible causes are as follows :

1 Invalid axis numbers have been assigned to move or compensation

axes.

2 The number of pitcherror compensation points between the maxi-

mum positive and maximum negative points exceeds 128.

3 Straightness compensation point numbers have been assigned in

other than ascending order.

4 Straightness compensation points could not belocated between the

maximum positive and maximum negative pitch error compensation

points.

5 The amount of compensation per compensation point is too large or

too small.

5073 NO DECIMAL POINT A decimal point is not specified for a command for which a decimal point

must be specified.

5074 ADDRESS DUPLICATION ERROR The same address appears more than once in a block. Alternatively, a

block contains two or more G codes belonging to the same group.

5134 FSSB : OPEN READY TIME OUT Initialization did not place FSSB in the open ready state.

5135 FSSB : ERROR MODE FSSB has entered error mode.

5136 FSSB : NUMBER OF AMPS IS SMALL In comparison with the number of controlled axes, the number of amplifi-

ers recognized by FSSB is not enough.

5137 FSSB : CONFIGURATION ERROR FSSB detected a configuration error.

5138 FSSB : AXIS SETTING NOT COM-

PLETE

In automatic setting mode, axis setting has not been made yet.

Perform axis setting on the FSSB setting screen.

5139 FSSB : ERROR Servo initialization did not terminate normally.

The optical cable may be defective, or there may be an error in connec-

tion to the amplifier or another module.

Check the optical cable and the connection status.

5195 DIRECTION CAN NOT BE JUDGED When the touch sensor with a single contact signal input is used in the

direct input B function for tool offset measurement values, the stored

pulse direction is not constant. One of the following conditions exists:

· The stop state exists in offset write mode.

· Servo off state

· The direction varies.

· Movement takes place simultaneously along two axes.

5197 FSSB : OPEN TIME OUT The CNC permitted FSSB to open, but FSSB was not opened.

5198 FSSB : ID DATA NOT READ Temporary assignment failed, so amplifier initial ID information could not

be read.
