PERIODIC MAINTENANCE OF BATTERY FOR THE ABSOLUTE PULSECODER
1. BATTERY FOR THE ABSOLUTE PULSECODER
When the interface with the CNC is type B or FSSB, the battery for the absolute pulse coder is
required for absolute-position detection.
The battery for the absolute pulse coder is installed in the following two methods:
Method 1: Installing a special lithium battery in the SVM
. Use A06B-6114-K504.
. A battery case (A06B-6114-K505 or A06B-6079-K500) is required.
Method 2: Using a battery case (A06B-6050-K060)
. Use A06B-6050-K061 or a commercially available
R20 alkaline dry cell.
. A connection cable (A06B-6093-K810) is required.
Use Name
Order specification
drawing No.
Remarks Classifi-
cation
Battery A06B-6114-K504 Adapted the U.N. advice
A06B-6114-K505 For other than SVM1-240,360
Method 1
Battery Case
A06B-6079-K500 For SVM1-240, SVM1-360
Battery A06B-6050-K061 Four R20 alkaline dry cells
Battery case A06B-6050-K060 For four R20 alkaline dry cells
Cable for battery
connection
A06B-6093-K810
Method 2
Connector for battery
connection
A06B-6093-K303
Option
CAUTION
In the case of the old battery (A06B-6073-K001), the battery cover attached
to servo amplifier was able to be used as a battery case, but in using the
new battery (A06B-6114-K504), the battery case (A06B-6114-K505 or
A06B-6079-K500) is newly required.
