Series 30i-MODEL A, Tool management function oversize tools support Specifications Additional Manual Page 6

Additional Manual
A-79346E
Title
Draw
No.
Ed. Date Design Description
Date Jan.06.’04 Design. Apprv.
4/22
page
FANUC Series 30i-MODEL A
Tool management function oversize
tools su
pp
ort
Pot No.
(Row-Column)
Tool management
No.
Pot No.
(Row-Column)
Tool management
No.
Pot No.
(Row-Column)
Tool management
No.
1(01-01) * 11(03-01) * 21(05-01) 8
2(01-02) * 12(03-02) * 22(05-02) 0
3(01-03) * 13(03-03) * 23(05-03) 0
4(01-04) 0 14(03-04) 0 24(05-04) 4
5(01-05) 5 15(03-05) 6 25(05-05) 0
6(02-01) * 16(04-01) 2
7(02-02) 1 17(04-02) 0
8(02-03) * 18(04-03) 7
9(02-04) 0 19(04-04) *
10(02-05) 0 20(04-05) 3
Cartridge management table
Oversize tool
Pots occupied by large-diameter tool
Tool figure No. Left direction Right direction
Upper direction Lower direction
Figure
1 2 2 2 2 A
2 1 1 1 1 A
3 2 3 3 1 A
4 2 0 0 0 A
5 2 2 2 2 A
Omitted
19 1 3 2 2 A
20 2 2 4 4 A
Tool figure setting screen
NOTE
・Even if a tool figure number is set in the tool management data, the tool
is regarded as a normal tool when the tool information #2 is set to 0.
・If all data items corresponding to a tool figure number are set to 0 (0 for
the upper, lower, left, and right directions), the tool is regarded as a
normal tool even when the tool information #2 is set to 1.
Tool figure setting screen
The area occupied by a tool depends on whether the tool is stored in a cartridge of matrix
type or a cartridge of chain type. A tool stored in a cartridge of matrix type occupies pots in
the upper, lower, left, and right directions. A tool stored in a cartridge of chain type
occupies pots only in the left and right directions.
