Series 21i/210i - MB Operators manual Page 397

Operators manual
PROGRAMMING
B–63614EN/01
19. HIGH SPEED CUTTING
FUNCTIONS
373
NOTE
1 The overlapping rapid traverse blocks is ineffective.
2 In case of using bell–shaped type acceleration /
deceleration, the option of rapid traverse bell–shaped
acceleration / deceleration is necessary.
(6) Specifications list
Controlled axis
f : It is possible to command.
× : It is not possible to command.
Item Function
Controlled axes number 3 axes – 4 axes
In case of using 4 axes, the option of controlled
axes expansion is needed.
Simultaneously
controlled axes
Max. 4 axes
In case that the simultaneously controlled axes are
more than 3 axes, the option of simultaneously
controlled axes expansion is needed.
Axis name Basic 3 axes are X, Y, Z.
Others are optional from U, V, W, A, B, C.
Least input increment 0.001mm, 0.001deg, 0.0001inch
Increment system 1/10 0.0001mm, 0.0001deg, 0.00001inch
The option of increment system 1/10 is needed.
Increment system 1/10 for each axis can not be
used.
Inch/metric conversion
(G20,G21)
f(The option of inch/metric conversion is
needed) (Note2)
InterpolationFunction f : It is possible to command.
× : It is not possible to command.
Item Function
Positioning (G00) f
Single direction
positioning (G60)
×
Exact stop (G09) f
Exact stop mode (G61) f
Tapping mode (G63) f
Automatic corner
override (G62)
×
Linear interpolation
(G01)
f
Circular interpolation
(G02, G03)
f (Multi–quadrant is possible.)
