FS 16i Additional Manual Page 13

Additional Manual
2002/03/20 T.Horie
A-78672EN
FANUC Series 16i-MB
Jerk Control Specifications
Title
Drawing No.
Page
Descri
p
tionDate Edit
12/15
(Look-ahead bell-shaped acceleration/deceleration
before interpolation)
(Look-ahead smooth bell-shaped
acceleration/deceleration before interpolation)
Time
Tangential
speed
Time
Time
A
cceleration
Jerk
Tangential
speed
Time
A
cceleration
Jerk
Time
Time
Acceleration change time
Time specified in parameter
No. 1772 or No.8416
Jerk change time
Time at a ratio specified
in parameter No. 1790 or
No.19524 to the
acceleration change time
