POWER MATE i-MODEL D/H Operation and maintenance handbook Page 14

Operation and maintenance handbook

Page of 396

/ 396

SAFETY PRECAUTIONS

s–12

6. RENAMING OF PMC MODELS

This manual presents programming descriptions for the PMC models

listed in the following table. Note that some models have been renamed;

in the product name column, the old names are enclosed in

parentheses, while the new names appear above the old names.

However, the previous specifications are still applied to the renamed

models. Thus, when using the renamed models, users should:

D Read the old names shown in this manual as the new names.

D Read the old names appearing on the units as the new names.

Table. PMC Model Name

Product Name Abbreviations

FANUC PMC–MODEL SB5

(Old name: FANUC PMC–MODEL RB5)

PMC–SB5

(PMC–RB5)

FANUC PMC–MODEL SB6

(Old name: FANUC PMC–MODEL RB6)

PMC–SB5

(PMC–RB5)
