2. OPERATION LIST

Program editing

Function

KEY

PWE

= 1

Mode

Function

key

Operation

Deletion of

all pro-

grams

f EDIT [F2] [O] → [–9999] → [Delete]

Deletion of

one pro-

gram

f EDIT [F2] [O] → Program No. →

[Delete]

Deletion of

multiple

blocks

f EDIT [F2] [N] → Sequence No. →

[Delete]

Deletion of

one block

f EDIT [F2] [;] + [Delete]

Word

deletion

f EDIT [F2] Search for word to be de-

leted → [Delete]

Word

alteration

f EDIT [F2] Search for word to be

changed → New word →

[Home]

Word

insertion

f EDIT [F2] Search for word immediately

before insertion location →

New word → [Insert]

I/O to and from FANUC Cassette

Function

KEY

PWE

= 1

Mode

Function

key

Operation

File head

EDIT [F2] [N] → FILE No. → [F7]

File

deletion

f EDIT [F2] [N] → FILE No. → [Delete]

Program

registra-

tion

f EDIT [F2] [N] → FILE No. → [F7]

Output of

all pro-

grams

EDIT [F2] [O] → –9999 → [F8]

Output of

one pro-

gram

EDIT [F2] [O] → Program No. → [F8]

Program

collation

EDIT [F2] File head search → [N] →

FILE No. → [F7]

Play–back

Function

KEY

PWE

= 1

Mode

Function

key

Operation

NC data

input

f TJOG

THND

[F2] Move machine. → [X], [Y] or

[Z] → [Insert] → NC data →

[Insert] → [EOB] → [Insert]
