POWER MATE i-MODEL D/H Operation and maintenance handbook Page 335

Operation and maintenance handbook

Page of 396

/ 396

9. ERROR CODE LIST

315

Number ContentsMessage

410 SERVO ALARM: n–TH AXIS

– EXCESS ERROR

Either of the following errors oc-

curred.

1) For the n–th axis, the positional

deviation while the operation

was stopped exceeded the value

set in parameter No. 1829.

2) For simple synchronous control,

the amount of compensation for

synchronization matching ex-

ceeded the value set in parame-

ter No. 8325.

This alarm is issued only for a

slave axis.

411 SERVO ALARM: n–TH AXIS

– EXCESS ERROR

The position deviation value when

the n–th axis (axis 1–8) moves is

larger than the set value.

Refer to procedure of troubleshoot-

ing.

413 SERVO ALARM: n–th AXIS

– LSI OVERFLOW

The contents of the error register for

the n–th axis (axis 1–8) exceeded

power. This error usually oc-

curs as the result of an improperly

set parameters.

415 SERVO ALARM: n–TH AXIS

– EXCESS SHIFT

A speed higher than 511875 units/s

was attempted to be set in the n–th

axis (axis 1–8). This error occurs as

the result of improperly set CMR.
