FANUC Series 30i-A/31i-A5 Tool Posture Control of Toll Center Point Control for 5-axis Machining Additional Manual Page 3

Additional Manual
Ed.
Apprv.
Person
Page
Name No.
Date
Person
Contents
Date
FANUC Series 30i-A/31i-A5
Tool Posture Control of Toll Center Point Control
for 5-axis Machining
A
-79294E
2004.2.25
3
/
12
FANUC LTD.
2004.4.12
02
The part of (2) is changed.
2004.9.22
03
The function name is updated.
2004.11.16
04
The part of (4) is changed.
2004.12.17
05
The part of (5) is changed.
Format
Tool Posture Control
G43.4 IP
α β H P ; Tool Center Point control (TYPE1)
G43.5 IP
H Q P ; Tool Center Point control (TYPE2)
IP : In the absolute mode, the end position of Tool Center Point
In the incremental mode, the movement value of Tool Center
Point
α, β : In the absolute mode, the end position of Rotay axes
In the incremental mode, the movement value of Rotary axes
H : Tool offset number
Q : Tool inclination angle (degree)
P : Selection for Conventional control (P0) or Tool posture control
(P1)
Here, the parameter TPC (No.19604#0)
can also select the way of controls, when P is not commanded.
At the block of G43.4 or G43.5, when ”P0” is commanded, Conventional control
works, and when ”P1” is commanded, Tool Posture Control works.
When P is not commanded at the block G43.4 or G43.5, the parameter TPC
(No.19604#0) can also select the way of controls.
The control way (Conventional control or Tool posture control) selected at the
block of G43.4 or G43.5 is active until G49 is commanded.
(4)
