B–62073E/04

6. CONNECTION OF I/O UNITS TO

MACHINE INTERFACE

196

DAL1 out: Normal state

lit: Error occurred on DO outputs Yq+0.0 to Yq+0.7

DAL2 out: Normal state

lit: Error occurred on DO outputs Yq+1.0 to Yq+1.7

DAL3 out: Normal state

lit: Error occurred on DO outputs Yq+2.0 to Yq+2.7

DAL4 out: Normal state

lit: Error occurred on DO outputs Yq+3.0 to Yq+3.7

DAL5 out: Normal state

lit: Error occurred on DO outputs Yq+4.0 to Yq+4.7

DAL6 out: Normal state

lit: Error occurred on DO outputs Yq+5.0 to Yq+5.7

DAL7 out: Normal state

lit: Error occurred on DO outputs Yq+6.0 to Yq+6.7

DAL8 out: Normal state

lit: Error occurred on DO outputs Yq+7.0 to Yq+7.7

System alarms generated by the above alarms are as follows.

For details, refer to “Appendix C. 3 (3) –(18) SLC ERROR of the FANUC

Series 15/150–MODEL B Maintenance Manual (B–62075).”

“SLC–ERROR aa(bb)” Example “SLC ERROR 03(41)”

(aa: XXXXXX11

Binary bits 0 and 1 are “1”. Other bits are not fixed.)

(bb: X1XXXXX1

Binary bit 6 is “1”. Bits other than bit 0 to 4, and 6 are not fixed.)

The value obtained by subtracting “1” from the value indicated by bits 0

to 4 is the I/O group number where the error occurred.

The above example shows I/O alarms that have occurred in group O.

Setting pin “CP1” settings are as follows:

Open: CNC is not notified of alarm.

Short: CNC is notified of alarm.
