An uncontinuous point of scale data
Before using this function, it is necessary to know the position of the
uncontinuous point. By the following process, the position of the uncontinuous
point can be found in the case of an absolute position detector (absolute pulse
coder).
1. Perform a reference position return with the parameter No.1817#3=0.
→ The correspondence between the reference position and position in
the absolute-position detector has been established. (parameter No.1815#4=1)
2. Record machine coordinate value after moving to one side of end of movable range.
3. Turn the CNC off and on.
・In the case that the machine coordinate value misses by the amount of one rotation :
→Go to the process 7 because an uncontinuous of scale data exists within movable range.
・In the case that the machine coordinate value does not miss and CNC starts normally :
→Record the machine coordinate value after moving to the other side of end of movable range.
4. The machine coordinate value before and after the power supply turning on are compared.
5. Turn the CNC off and on.
・In the case that the machine coordinate value misses by the amount of one rotation :
→Go to the process 7 because an uncontinuous of scale data exists within movable range.
・In the case that the machine coordinate value does not miss and CNC starts normally :
→There is not an uncontinuous point within movable range.
6. The machine coordinate value before and after the power supply turning on are compared.
It is unnecessary to use the parameter No.1817#3.
(No.1817#3=0)
7. Record the machine coordinate value after moving by a constant interval (10 degree,
for example) from present position for an inside of movable range.
8. Turn the CNC off and on.
・Until exceeding an uncontinuous point, the CNC starts on wrong position.
→Repeat process 7 and 8.
・After exceeding an uncontinuous point, the CNC starts on correct position.
→By the above process it is possible to know the approximate position of the unc
ontinuous
point.
