Signal manipulation <2> above is required to establish a one-to-one correspondence between the
commands and the spindle of the path for which the commands are to be selected in the system
configuration in the above example.
Spindle command selection signals may be handled differently depending on the number of
CNC-controlled paths and the number of controlled spindles (parameter No. 3703 #0, #2).
3. PARAMETER
SPR
#1 #0 #2#3#4#5#7 #6
3703
Data type: Bit type, common to all paths
SPR On 2- or 3-path lathe, the spindle with which to perform rigid tapping is:
1: Spindle of the path selected with a spindle command selection signal (SLSPA or SLSPB).
0: Spindle of the path for which a rigid tapping command has been issued.
By setting this parameter bit to 1, you can select the spindle with which to perform rigid tapping
with a similar signal operation as that with an S command.
Note 1) If you set this parameter bit, you must turn the power off and back on for the setting to take
effect.
Note 2) If you use this function to perform rigid tapping with the spindle connected to another path,
the parameters listed below will follow the settings of the path to which the spindle is
connected:
No.3706#0,#1,No.3707#0,#1,No.3707#2,#3
No.5200#1,No.5200#4,No.5201#2,No.5201#3,No.5204#1
No.5211 (extraction override value)
No.5214,5215,5216 (synchronous error width)
Nos. 5221 to 5224, No. 5225, 5226, No. 5227, 5228
(number of teeth on the spindle)
Nos. 5231 to 5234, No. 5235, 5236, No. 5237, 5238 (number of teeth on the PC)
Nos. 5241 to 5244, No. 5245, 5246, No. 5247, 5248 (maximum speed)
Nos. 5261 to 5264,No. 5265, 5266, No. 5267, 5268
(acceleration/deceleration time constant)
