Servo Amplifier Unit Alpha Series Descriptions Page 21

Descriptions
2. CONFIGURATION
B–65192EN/02
5
Table 2.1.3 Type of Unit and Designation (1)
Group
Name Applcation Designation
Basic AC line filter Type A: 5.4kW A81L–0001–0083#3C
(Caution 1)
Type B: 10.5kW A81L–0001–0101#C
Type C: 23kW A81L–0001–0102
Option Power Type SAE: 2.2kVA A80L–0022–0005
transformer
for export
Type SBE: 3.5kVA A80L–0024–0006
for export
(Caution 2)
Type SCE: 5.0kVA A80L–0026–0003
(Caution 2)
Type SDE: 7.5kVA A80L–0028–0001
Option Separate
Regenerative
For A06B–6089–H101 to –H102
(16Ω/100W, at natural cooling)
A06B–6089–H510
Discharge Unit
(Caution 3)
For A06B–6089–H101 to –H105, –H201 to –H210,
A06B–6090, –H003 to –H006, –H222 to –H266
(16Ω/200W, at natural cooling)
A06B–6089–H500
For A06B–6089–H104 to –H105, –H201 to –H210,
A06B–6090–H004 to –H006, –H222 to –H266
(16Ω/800W, With cooling fanmotor)
A06B–6089–H713
For A06B–6089–H104 to –H105, –H201 to H210,
A06B–6090–H004 to –H006, –H222 to –H266
(16Ω/1200W, With cooling fanmotor)
A06B–6089–H714
For A06B–6089–H106, A06B–6090–H008
(8Ω/800W, With cooling fanmotor)
A06B–6089–H711
For A06B–6066–H106, A06B–6090–H008
(8Ω/1200W, With cooling fanmotor)
A06B–6089–H712
2.1.3
Othes
