1. Fanuc
  2. Series 30i/300i/300is/31i/310i/310is/32i/320i/320is-MODEL A

Series 30i/300i/300is/31i/310i/310is/32i/320i/320is-MODEL A Additional Manual Page 11

Additional Manual
Series 30i/ 31i/ 32i-A
C executor library for conversion
Programming manual
01 04.05.06
S. Hasegawa
New registration
B-64183EN/01
EDIT
DATE
DESIG.
DESCRIPTION
11/226
DRAW.NO.
2.1
INSTALLATION OF THE "C LIBRARY FOR CONVERSION"
ON A PERSONAL COMPUTER
The development environment of C executor
The "C library for conversion" has to be installed on the development
environment of C executor on a personal computer. If a C compiler and
the "C library for C executor" have not been installed on a personal
computer, install them. About the installation of C compiler and the "C
library for C executor", refer to the following manual.
・ "C language executor operator's manual B-63944EN-3"
C library for conversion
The files and directories structure of the installation CD-ROM of the "C
library for conversion" is shown below.
pmclib.h Header file
clblib.o Library file
The example of files and directories structure of the development
environment of C executor is shown below.
To install the "C library for conversion",
(1) Copy the file "pmclib.h" into "inc" directory.
(2) Copy the file "clblib.o" into "lib" directory.
<CD-ROM>
inc
pmclib.h
lib
clblib.o
<Install directory of the C library for C executor>
inc
<- pmclib.h
lib
<- clblib.o
man
tool
user
