3.10.2
Close the Reader / Puncher Interface
[Name]
pl_rsclose2
[Syntax]
#include <pmclib.h>
short pl_rsclose2(short channel);
[Arguments]
Input
channel: Channel number of RS-232C
Set the channel number (1-) of RS-232C.
Output
---
[Return]
0: Normal completion.
5: The argument is invalid.
[Description]
This function closes the reader / puncher interface.
You should close the interface by the calling of pl_rsclose2() after the
calling of pl_rsrd2() or pl_rswrt2().
When you open the interface using the pl_rsopen(), you cannot use the
function pl_rsclose2(). You should use the pl_rsclose().
When you use this function, you cannot use the conventional function
related to the RS-232C communication in "C library for C executor"
together.
[Related Function]
rs_close(), fca_close()
