Series 30i/ 31i/ 32i-A
C executor library for conversion
Programming manual
01 04.05.06
S. Hasegawa
New registration
B-64183EN/01
EDIT
DATE
DESIG.
DESCRIPTION
88/226
DRAW.NO.
3.8
CHARACTER DISPLAY
3.8.1
Color Palette for the Character Display
On the character screen, you can set current color by the palette number,
from 0 to 15. The correspondence of the palette number to the default
color is shown below.
Palette
number
Color R G B
0 Black 0 0 0
1 Red 0x3f 0 0
2 Green 0 0x3f 0
3 Yellow 0x3f 0x3f 0
4 Blue 0 0 0x3f
5 Magenta 0x3f 0 0x3f
6 Cyan 0 0x3f 0x3f
7 White 0x3f 0x3f 0x3f
8 Dark gray 0x18 0x18 0x18
9 Dark red 0x1c 0x0c 0x0c
10 Dark green 0x0c 0x1c 0x0c
11 Dark yellow 0x1c 0x1c 0x0c
12 Dark blue 0x0c 0x0c 0x1c
13 Dark magenta 0x1c 0x0c 0x1c
14 Dark cyan 0x0c 0x1c 0x1c
15 Light gray 0x28 0x28 0x28
