FANUC Series 30i/31i-MODEL A Specifications for Speed Command Extension in Least Input Increments D and E Additional Manual Page 3
Additional Manual
A-79510E
Title
Draw
No.
Ed. Date Design Description
Date Sep.10.’04 Design. Apprv.
3/6
page
FANUC Series 30i/31i-MODEL A
Specifications for Speed Command Extension
in Least Input Increments D and E
- Parameters for speed and angular velocity when this function is used
Unit of data
Increment
system
Least data
increment
Valid data range
IS-D 0.0001 0.0000 to +99999.9999 mm/min
deg /min
IS-E 0.0001 0.0000 to +99999.9999
IS-D 0.00001 0.00000 to +4000.00000
inch/min
IS-E 0.00001 0.00000 to +4000.00000
Table 3
- Parameters for acceleration/deceleration and angular acceleration/deceleration when
this function is used
Unit of data
Increment
system
Least data
increment
Valid data range
IS-D 0.0001 0.0000 to +99999.9999 mm/sec
2
deg/sec
2
IS-E 0.0001 0.0000 to +99999.9999
IS-D 0.00001 0.00000 to +9999.99999
inch/sec
2
IS-E 0.00001 0.00000 to +9999.99999
Table 4
NOTE
The least data increment and the valid data range of
setting value is different from the former ones.
