FANUC Series 30i/31i-MODEL A Specifications for Speed Command Extension in Least Input Increments D and E Additional Manual Page 5
Additional Manual
A-79510E
Title
Draw
No.
Ed. Date Design Description
Date Sep.10.’04 Design. Apprv.
5/6
page
FANUC Series 30i/31i-MODEL A
Specifications for Speed Command Extension
in Least Input Increments D and E
Parameter
#7 #6 #5 #4 #3 #2 #1 #0
1013 IESP
[Input type] Parameter input
[Data type] Bit axis
# 7 IESP When the least input increment is D(IS-D) or E(IS-E), the function to allow
to set the larger value to the parameter of the speed and the acceleration:
0: Not used.
1: Used.
As for the axis which set this parameter when the least input increment is
D(IS-D) or E(IS-E), the larger value can be set to the parameter of the speed
and the acceleration.
When this function is made effective, the digit number below the decimal
point of the parameter on input screen is changed. The digit number below
the decimal point decreases by one digit in case of the least input increment
D(IS-D), and it decreases by two digits in case of the least input increment
E(IS-E).
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
