To Meet the Requirement of the EMC Directive Additional Manual Page 16

Additional Manual
A-72937EN/11
To meet the requirement of the EMC Directive
TMN06007E_A-72937EN_11.DOC
- 14 -
Recommendable noise filters for EMC (8)/
For neutral point grounding system
only
PSM-5.5, PSMR PSM-11, 15 PSM-26 ~ 37
α,β
SVU1, 2, 3 ／ βseries
α(HV)
－
PSM-18HV, 30HV
PSMV-11HV
PSM-45HV
Power
supply
module
αi
PSM-5.5i PSM-11i , 15i PSM-26i
~
37i
Rated current
30A 75A 180A
Rated voltage
AC480V
Outer dimension
Annex 3-Fig.7
Weight
about 1.8 kg about 4 kg about 11 kg
Number of phase
3-phase
Withstanding
voltage
Between the terminal and the case : DC2800V, 2 second
Between the terminal and terminal : DC1700V, 2 second
Insulation
resistance
Between the terminal and the case : 2.18MΩ
Leakage current
※26.5mA ※28.2mA ※32.8mA
Operating
temperature
-25℃～50℃
Filter model
(SCHAFFNER)
FN258-30 FN258-75 FN258-180
※These values are of earthed neutral star system at 480V/50Hz.
※SCHAFFNER’s agency in Japan is Unidux LTD.
Recommendable noise filters for EMC (9)/
For neutral point grounding system
only
PSM-5.5, PSMR PSM-11, 15 PSM-26 ~ 37
α,β
SVU1, 2, 3 ／ βseries
α(HV)
－
PSM-18HV, 30HV
PSMV-11HV
PSM-45HV
αi
PSM-5.5i PSM-11i , 15i PSM-26i
~
37i
Power
supply
module
α(HV)i PSM-11HVi
PSM-18HVi
PSM-30HVi
PSM-45HVi
Rated current
30A 75A 180A
Rated voltage
AC480V
Outer dimension
Annex 3-Fig.8
Weight
about 1.2kg about 3.2kg about 6kg
Number of phase
3-phase
Withstanding
voltage
Between the terminal and the case : DC2800V, 2 second
Between the terminal and terminal : DC1700V, 2 second
Insulation
resistance
Between the terminal and the case : 2.18MΩ
Leakage current
※ 33.04mA
Operating
temperature
-25℃～100℃
Filter model
(SCHAFFNER)
FN3258-30 FN3258-75 FN3258-180
※These values are of earthed neutral star system at 480V/50Hz.
※SCHAFFNER’s agency in Japan is Unidux LTD.
The outer dimensions are shown in Annex 3.
Each noise filter is provided with a M4 or M6 stud for grounding (see annex
3). Provide a grounding terminal close to the unit and connect the terminal
and the stud by a wire more than 5.5 mm
２
and less than 10 cm. The noise
filters should be mounted directly on a surface inside of a metal cabinet with
no paint in the contact area or on a surface inside of a metal cabinet with stud
bolts attached on a metal plate of a cabinet if painted.
