  2. Connection of Ethernet Connector Panel

Connection of Ethernet Connector Panel Additional Manual Page 3

Additional Manual
EDIT.
SHEET
DRAW. NO.
CUST.
TITLE
2
/
6
DESCRIPTIONDESIG.DATE
Connection of Ethernet Connecto
r
Panel
A
-65563EN/01
CAUTION
Before attaching or removing cables, power off the
CNC main unit, and confirm that the power is off.
Ask the respective manufacturers for explanations
about how to build a network and about conditions
for using units (such as a media converter, hub,
transceiver, and cable) other than the CNC unit.
When installing network cables, exercise sufficient
caution so that the network will not be affected by
any noise source. Electrically separate the network
wiring sufficiently from noise sources like motors
and their power lines. Also, ground each unit as
required. If the grounding impedance is high, it may
cause trouble in communication. Once the
equipment is installed, conduct communication
tests to verify normal operation before starting
actual use of the equipment. FANUC is not liable to
any damage related to trouble arising from any unit
other than the CNC unit.
Previous page
Next page

Contents Summary of Connection of Ethernet Connector Panel Additional Manual

  • Page 1TECHNICAL REPORT (MANUAL) NO.TMN 05/121E Date: Dec. 19, 2005 General Manager of CNC Laboratory Connection of Ethernet Connector Panel 1. Communicate this report to: ○ Your information ○ GE Fanuc-N, GE Fanuc-E FANUC Robotics MILACRON ○ Machine tool builder Sales agency End user 2. Summary for Sales D
  • Page 2Ethernet Connector Panel Ethernet Connector Panel enables user to connect/disconnect Ethernet cable at the front panel of the cabinet with ease. 1. Specification Name Specification A02B-0303-C194 with 1m cable Ethernet Connector Panel A02B-0303-C195 with 2m cable A02B-0303-C196 with 5m cable A02B-03
  • Page 3CAUTION Before attaching or removing cables, power off the CNC main unit, and confirm that the power is off. Ask the respective manufacturers for explanations about how to build a network and about conditions for using units (such as a media converter, hub, transceiver, and cable) other than the CNC
  • Page 43. Connection of Ethernet Connector Panel CNC Ethernet Connector Panel CD38x CD51 CD38 1 TPTX＋ 1 TPTX＋ Attached cable 2 TPTX－ 2 TPTX－ 3 TPRX＋ 3 (0V) 4 4 (+24V) 5 5 TPRX＋ 6 TPRX－ 6 TPRX－ 7 7 (+24V) 8 8 (0V) CPD20 1 (+24V) 24V input (*1) 2 (0V) 3 FG Cable connection CD38 (RJ-45) CD51 TPTX+ 1 1 TPTX+ T
  • Page 54. Connection of Ethernet Cable for Connector Panel Ethernet Connector Panel CD51 Peripherals side 1 TPTX＋ connector CD51 2 TPTX－ PC or HUB (line 3 (0V) concentrator) 4 (+24V) 5 TPRX＋ 6 TPRX－ 7 (+24V) 8 (0V) Cable connection [Cross cable] Peripherals CD51 side connector 1 3 TPTX+ TPRX+ TPTX- 2 6 TPR
  • Page 6・Recommended cable side connector (note1) CD51 side: JB5DT08YN121 (Japan Aviation Electronics) Peripheral side: TMP21P-88P (Hirose Electric) ・Recommended cable conductor : A66L-0001-0453 ・Maximum cable length: 40m (in case of recommended cable) Do not make the cable longer than necessary. ・Recommend
  • Page 75. Dimensions of Ethernet Cable for Connector Panel 2 mm 80 mm 14 mm 35 mm 125 mm Crimp terminal M4 Space for the connector Dashed line: Area for packing attachment panel cover 4-M 70 mm 3 80 mm 115 mm 64 mm 123 mm 109 mm Space for the connector panel cover and cable 78 mm 110 mm Panel cut drawing W
