Series 16i/160i-LA Operators manual Page 203

Operators manual

Page of 820

/ 820

PROGRAMMING

B–63194EN/02

12. COMPENSATION FUNCTION

183

(1) Removal of the vector causing the interference

When cutter compensation is performed for blocks A, B and C and

vectors V

, V

and V

between blocks A and B, and V

, V

and V

between B and C are produced, the nearest vectors are checked

first. If interference occurs, they are ignored. But if the vectors to be

ignored due to interference are the last vectors at the corner, they

cannot be ignored.

Check between vectors V

and V

Interference ––– V

and V

are ignored.

Check between V

and V

Interference ––– V

and V

are ignored

Check between V

and V

Interference ––– V

and V

are Ignored

Check between V

and V

Interference ––––– V

and V

are cannot be ignored

If while checking, a vector without interference is detected,

subsequent vectors are not checked. If block B is a circular

movement, a linear movement is produced if the vectors are

interfered.

(Example 1) The beam moves linearly from V

to V

Beam

center path

Programmed

path

, V

: Interference

, V

: Interference

, V

: Interference

, V

: No Interference

D Correction of

interference in advance
